Frame
300 Series Alpha Aluminium, tapered head tube, Internal cable routing, 3S chain keeper, T47 BB, rack and mudguard mounts, integrated frame bag mounts, flat-mount disc, 142x12 mm thru-axle
Fork
Checkpoint, full carbon, tapered carbon steerer, rack mounts, fender mounts, flat mount disc, 12x100mm thru axle
Weight
56 - 10.61 kg / 23.4 lbs (with TLR sealant, no tubes)
Weight Limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg (275 lb).
Shifter
Shimano Sora R3000, 9-speed
Front Derailleur
Shimano Sora R3000, 31.8 mm clamp
Rear Derailleur
Shimano Sora R3000, mid cage, 34T max cog
Crank
Size: 49 FSA Omega, 46x30, 165 mm length; Size: 52, 54 FSA Omega, 46x30, 170 mm length; Size: 56, 58 FSA Omega, 46x30, 172.5 mm length; Size: 61 FSA Omega, 46x30, 175 mm length
Cassette
Shimano Sora HG400, 11-32, 9-speed
Chain
Shimano Sora HG53, 9-speed
Max. Chainring Size
See service manual
Skewer Front
Bontrager Switch thru axle, removable lever
Skewer Rear
Bontrager Switch thru-axle, removable lever
Tyre
Bontrager Girona Pro, Tubeless Ready, GR puncture protection, aramid bead, 60 tpi, 700x42 mm
Tyre Part
Bontrager TLR sealant, 180 ml/6 oz
Rim Strip
Bontrager TLR
Max Tyre Size
See service manual
Saddle
Size: 49, 52 Bontrager Verse Comp, steel rails, 155 mm width; Size: 54, 56, 58, 61 Bontrager Verse Comp, steel rails, 145 mm width
Seatpost
Bontrager alloy, 27.2 mm, 12 mm offset, 330 mm length
Handlebar
Size: 49 Bontrager Elite Gravel, alloy, 38 cm width; Size: 52 Bontrager Elite Gravel, alloy, 40 cm width; Size: 54, 56 Bontrager Elite Gravel, alloy, 42 cm width; Size: 58, 61 Bontrager Elite Gravel, alloy, 44 cm width
Handlebar Tape
Bontrager Supertack Perf tape
Brake
Tektro C550 mechanical disc brake, dual piston, flat mount
Brake Rotor
Tektro, CentreLock, 160 mm
Rotor Size
Max brake rotor sizes: 160 mm front and rear
